Lead-Acid Battery Charger, 120W, Single Output, 3-stage Control AD1120CF.Series manufacturer from Taiwan Acro Engineering Inc.

Lead-Acid Battery Charger, 120W, Single Output, 3-stage Control

Payment Terms:	T/T,
Place of Origin:	Taiwan


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: AD1120CF.Series

-Dimension : 121 (D) x110 (W) x75 (H) mm
-Input voltage : 100 ~ 240VAC
-Input Frequency : 47 ~ 63HZ
-Inrush current : 22A/115VAC

# 120 W / Single Output / 3-stage Control #
-Universal input range(100~240VAC/47~63Hz)
-High Power density
-RoHs, CE, CB, TUV, UL certification
-3-year warranty
-Great reliability
-Convection cooled
-Over voltage protection
-Overload protection
-Short circuit protection
-DIN Rail / Wall Bracket mounting solution

AD1120CF is designed to recharge Lead – Acid battery used by electronic vehicles, medical appliances etc. Acro built an inner 3-stage charge control to provide a safe and effective Lead-Acid battery charger. The 3-stage charge control would adjust the level of current to fill up the battery in a stable way. This function not only provides a steady way to fill up battery but also lengthens the life of batteries.
